Description
The Google Drive Upload component allows you to upload files to Google Drive.
Transfer result data processed by Gravio to Google Drive
Upload and save device data to Google Drive as log data on a regular basis. This is for example useful to regularly upload CSV, Excel files, and image data acquired from cameras etc.
| Output Payload | Description |
|---|---|
cv.Payload | output payload of the previous component as is. (pass-through) |
Component Properties
| Property Name | Description |
|---|---|
| Input | payload or filename |
| filename | File name to be sent if "Input Properties" is a file name. |
| Content-Type | Content-Type of HTTP header |
| Designation Method | Folder path or folder ID |
| Drive folder path | Google Drive destination folder name |
| FileID | Google Drive destination folder ID |
| timeout | HTTP request response timeout value |
| OAuth2 Client ID | Client ID of API 2.0 from GCP ※1 |
| OAuth2 Client Secret | Specify Client Secret from GCP ※1 |
| OAuth2 Redirect URL | Specify Redirect URL from GCP ※1 |
| OAuth2 Access Token | Press the Get Token button to get the token. You can also update the token by pressing the Update button ※1 ※2 |
See Google Drive OAuth2 Setup for an example of OAuth2 configuration in GCP.
Component Variables
| Component Variables | Description |
|---|---|
| cv.ContentType | Content-Type of HTTP header |
| cv.FileID | File ID |
| cv.FolderID | Folder ID |
| cv.DriveFilename | Google Drive destination filename |
How to get OAuth2 Access Token
Go to the settings and open the Base Property Profiles view, add your Google Authentication.
Once you have inserted your Client ID and and Secret, you can click on the "Obtain" button to retrieve your token using your web browser.
OAuth2 access token button to display the Get OAuth 2.0 access token panel. Press the Open Browser button to obtain the token. Once the token is obtained, press the Set button to automatically set it to the OAuth2 access token property.
Follow the steps on your browser, and return to Gravio Studio to set the authentication.
