Description
The Parallel If component is a component that executes another action in parallel only if certain conditions are met, while continuing the currently running action.
This allows for the reuse of previously created actions.
Conditions for executing another action can be specified with expressions. If the condition evaluates to true, another action is also executed; if false, no other action is performed, but the current action continues. Variables with prefixes tp. / tv. / ap. / av. / cp. / cv. can be used as comparators in the conditional expressions.
Component Properties
| Property Name | Description |
|---|---|
| Action ID | The ID of the action to execute |
| Condition | The condition under which to execute the action |
| Example Conditions | Expression Examples |
|---|---|
| Targeting Payload, when Payload is numeric | cv.Payload > 10 |
| When Payload is a string | cv.Payload =~ "^abc" |
| When Payload is a JSON array | cv.Payload[1] > 10 |
| When Payload is a JSON Object | cv.Payload.key1 == "abc" |
Action ID
The name of the action, excluding the file extension (.acs), is the Action ID.
